- Wheel Diameter
- 100mm4＂
- Wheel Width
- 37mm1-1/2＂
- Wheel Bearing
- Wheels With Ball Bearings
- Plate Size
- 120 x 90mm4-13/16＂ x 3-9/16＂
- Bolt Hole Spacing
- 90 x 60mm3-9/16＂x 2-7/16＂
- Plate Hole
- 12mm1/2＂
- Offset
- 40.5mm1-5/8＂
- Swivel Interference
- 296mm11-3/4＂
- Overall Height
- 147mm5-7/8＂
- Swivel Radius
- 148mm5-15/16＂
- Hardness Of Tread
- 85±5° Shore A
- Load Capacity (Dynamic)
- 200kgs441lbs
- Load Capacity (Static)
- 300kgs661lbs
- Temperature
- -20°C to +80°C-4°F to +176°F
- Fork Type
- Swivel Caster With Front Brake
- Stainless
- N/A
- Electrical Conductivity
- N/A
- Anti-Static
- N/A
- Weight
- 3.19kgs7.0lbs
- Standard
- ISO22883
* For any deviation between metric and imperial spec, please refer to the metric spec.
