1146 46 Ascendant Series Caster Series(All Plastic)
Double-Ball Full-Effect Wheel (White-Dark Gray) Wheel Diameter × Wheel Width 75 × 14mm
KS-11460300266073
Wheel Diameter75mm
Load Capacity (Dynamic)90kgs
Overall Height84mm
Wheel BearingWheels With Ball Bearings
- Short-pedal total-lock caster，Threaded stem M12x15
- White bracket made of reinforced polypropylene
- Rust-resistant，Corrosion-resistant，Attractive appearance，Economical，Smooth swiveling
- Impact-resistant polypropylene wheel core，Thermoplastic elastomer（TPR）Tread
- Dark gray，Wheel bearing—Precision ball bearing，Small hub dust cover
- Tread：Thermoplastic rubber elastomer(TPR)
- Wheel core：Made of high-quality impact-resistant polypropylene
Product descriptions are for reference only. The actual product shall prevail.
3D drawings are for members only. Please log in to download.
Product Data Sheet
- Wheel Diameter
- 75mm
- Wheel Width
- 60mm
- Wheel Bearing
- Wheels With Ball Bearings
- Threaded Stem
- M12
- Threaded Length
- 15mm
- Offset
- 23mm
- Swivel Interference
- 180mm
- Overall Height
- 84mm
- Swivel Radius
- 90mm
- Hardness Of Tread
- 82±5° Shore A
- Load Capacity (Dynamic)
- 90kgs
- Load Capacity (Static)
- 130kgs
- Temperature
- -20°C to +60°C
- Fork Type
- Swivel Caster With Total Brake
- Stainless
- N/A
- Electrical Conductivity
- N/A
- Anti-Static
- N/A
- Weight
- 0.26kgs
- Standard
- ISO22881
* For any deviation between metric and imperial spec, please refer to the metric spec.
