YJ-12037708200304
Excellent Mechanical Properties and wear resistance
Excellent resistance to chemicals and corrosion
Suitable for use in Forklift Trucks, Electric Stackers, AGVs, and floor scrubbers
HPU, dark gray, surface machined with random texture A
Increases grip on the ground, effectively improving anti-slip ability
Wheel Tread: High-quality polyurethane
Product descriptions are for reference only. The actual product shall prevail.
Metric Imperial
Wheel Diameter（D） 200mm
Wheel Width（T2） 59mm
Wheel installation — Hub Lenth (T1) —
Wheel center-bore diameter (d) 135.3mm
Wheel Mounting Bolt Hole PCD Diameter —
Wheel Mounting Bolt Hole PCD 139.5mm
# Of Wheel mounting bolt boles —
Wheel mounting bolt hole (M) 3
Number of wheel mounting bolt holes 8 Load Capacity (Static) 1350kgs
Load Capacity at 4 km/h 900kgs
Load Capacity at 6 km/h 765kgs
Load Capacity at 10 km/h 630kgs Load Capacity at 16 km/h 360kgs
Hardness Of Tread 92±5° Shore A
Temperature -20°C to +70°C
Tread Pattern Scrambled Pattern A
Rolling Resistance ● ● ● ● ●
Operating Noise ● ● ● ● ●
Floor Surface Preservation ● ● ● ● ●
Wheel centre/ rim Iron core/electricity
Non-Marking Y
Conductive N/A 10^8/Ω～10^11/Ω
Anti N/A
Weight 2.39kgs
Standard ISO22883
