- Wheel Diameter
- 75mm3＂
- Wheel Width
- 41.5mm1-11/16＂
- Wheel Bearing
- Wheels With Ball Bearings
- Plate Size
- 115 x 100mm4-9/16＂ x 4＂
- Bolt Hole Spacing
- 85 x 70mm3-3/8＂x 2-3/4＂
- Plate Hole
- 20 x 11mm13/16＂ x 3/8＂
- Offset
- 56mm2-1/4＂
- Swivel Interference
- 270mm10-11/16＂
- Overall Height
- 120mm4-13/16＂
- Swivel Radius
- 135mm5-7/16＂
- Hardness Of Tread
- 87±5° Shore A
- Load Capacity (Dynamic)
- 260kgs573lbs
- Load Capacity (Static)
- 1000kgs2205lbs
- Temperature
- -20°C to +70°C-4°F to +158°F
- Fork Type
- Swivel Caster
- Stainless
- N/A
- Electrical Conductivity
- N/A
- Anti-Static
- N/A
- Weight
- 2.41kgs5.3lbs
- Standard
- ISO22883
* For any deviation between metric and imperial spec, please refer to the metric spec.
