ZQPU (brown round) Wheel Diameter x Wheel Width 100 x 22 (46.5) mm

YJ-11680400802023

Wheel Diameter100mm　

Load Capacity (Dynamic)320kgs　

Overall Height142.5mm　

Wheel BearingWheels With Ball Bearings

Height Adjustable Leveling Caster, Top Plate with Riveted Fork and European standard holes, Short Pedal
Zine-Plated, Mounting Type - Top Plate, Height Adjustable Stand
Cast Iron Wheel Center with High Quality Polyurethane tread
Brown, Bearing with Ball Bearing.
Wheel Tread: high quality polyurethane
Wheel Center: cast iron core

Product descriptions are for reference only. The actual product shall prevail.

3D drawings are for members only. Please log in to download.

Product Data Sheet

* For any deviation between metric and imperial spec, please refer to the metric spec.

Rolling Resistance

Operating Noise　

Floor Surface Preservation
